Bicycles & E-Bikes
Bearings for Bicycles & E-Bikes
Modern bicycles and E-bikes demand bearing solutions that balance ultra-low friction, minimal weight, and reliable sealing across road, gravel, and off-road conditions. As frame designs become lighter and drivetrain systems grow more complex, every bearing position from the wheel hub to the bottom bracket directly affects pedaling efficiency, ride quality, and component service life.
BOM manufactures needle roller bearings, headset bearings, one-way clutch integrated bearings, and gear integrated bearings engineered for bicycle hub, headset, drivetrain, and E-bike motor applications. With full-spectrum custom manufacturing capability — including non-standard envelope dimensions, integrated clutch and gear structures, and custom seal configurations — BOM delivers solutions where standard catalog bearings fall short:
- Ultra-low friction for maximum pedaling efficiency and longer battery range
- Thin-section and lightweight designs for weight-critical performance frames
- Multi-layer contact seals for rain, mud, dust, and high-pressure wash resistance
- Ceramic hybrid options (Si3N4 balls) for reduced rolling resistance and corrosion immunity
- Integrated one-way clutch and gear-bearing structures for E-bike drivetrains
- Full-specification custom manufacturing — dimensions, materials, coatings, and bearing structure
Low-Friction Efficiency
Every watt lost to bearing friction reduces pedaling efficiency and E-bike battery range. BOM manufactures bicycle bearings with precision-ground raceways and optimized internal geometry that minimize rolling resistance. Ceramic hybrid configurations further reduce friction by up to 30% compared to all-steel designs, delivering measurable gains in speed and range.
Lightweight & Compact
Performance bicycles count every gram. BOM manufactures thin-section bearings with reduced cross-section heights that save weight at hubs, headsets, and bottom brackets without sacrificing load capacity. The compact envelope allows frame designers to optimize tube profiles and hub geometry. Stainless steel and ceramic options further reduce weight in race-grade builds.
Sealed for All Conditions
Bicycles ride through rain, mud, road spray, and high-pressure washes. Standard seals often fail after a single wet season. BOM manufactures bearings with multi-layer contact seal structures that create effective barriers against water and contaminant ingress. The sealing geometry is optimized to balance protection with low rotational drag, maintaining efficiency in all weather.
BOM Products for Bicycles & E-Bikes
One-Way Bearing (Integrated Clutch Bearing)
BOM manufactures one-way clutch integrated bearings where the freewheel mechanism and bearing raceway are machined into a single housing. Used in E-bike hub drives and freehub assemblies for reliable one-way torque transmission with high concentricity.
View Product Details →Gear Integrated Bearing
Gear teeth and bearing raceway machined from one ring blank in a single setup. BOM manufactures gear integrated bearings for E-bike internal gear hubs and drivetrain modules, eliminating press-fit runout for smoother, more precise power transmission.
View Product Details →Needle Roller Bearings
Compact, high-capacity bearings for freehub ratchet mechanisms, pedal spindles, and suspension pivots. The small cross-section of needle rollers enables high load capacity within tight radial envelopes.
View Product Details →Headset Bearings
Angular contact ball bearings designed for bicycle steering columns. BOM manufactures headset bearings that handle combined radial and axial steering forces with smooth rotation, available in standard and integrated headset dimensions.
Application Cases
One-Way Integrated Bearing — E-Bike Hub Drives
E-bike hub drives require a freewheel mechanism that engages and disengages torque reliably at high pedal-assist speeds. Conventional designs use a separate one-way clutch pressed onto a bearing, but the concentricity error between the two components causes uneven clutch engagement, noise, and premature wear under the higher torque loads of electric-assisted cycling.
BOM manufactures one-way clutch integrated bearings where the clutch mechanism and bearing raceway are machined into a single housing. This eliminates concentricity error entirely, resulting in smooth, silent engagement and significantly longer service life. The integrated one-piece structure also reduces axial footprint and part count, freeing space within the hub shell for motor or battery components.
Gear Integrated Bearing — Internal Gear Hubs
Internal gear hubs (IGH) for city bikes and E-bikes rely on precise meshing between planetary gears and their supporting bearings. When the gear ring is press-fitted onto a separate bearing, the resulting runout degrades gear mesh accuracy, increases noise, and accelerates tooth wear across the planetary stages.
BOM manufactures gear integrated bearings where the gear teeth and bearing raceway are machined from the same ring blank in a single clamping setup. This delivers zero press-fit runout, ensuring consistent gear mesh contact and quieter operation across all gear ratios. The one-piece construction also increases load capacity by allowing custom wall thickness and enlarged rolling elements within the same envelope, extending the service life of the hub assembly.
Bearings for Bicycles & E-Bikes: Why Choose BOM?
Precision Bearings for the Cycling Industry
BOM Bearing is a professional manufacturer of precision bearings for bicycle and E-bike applications. BOM manufactures needle roller bearings, headset bearings, one-way clutch integrated bearings, and gear integrated bearings for bicycle OEMs, component brands, and E-bike drivetrain manufacturers, delivering consistent quality at volume production scale.
ISO 9001, IATF 16949, and ISO 14001 certified — quality and environmental standards validated at every production stage. Full-specification customization from non-standard dimensions and alternative materials to specialized coatings and complete bearing architecture redesign — engineered to your exact requirement.
Frequently Asked Questions
What is the difference between ceramic hybrid and all-steel bicycle bearings?
Ceramic hybrid bearings use silicon nitride (Si3N4) balls with steel raceways, while all-steel bearings use chrome steel balls and races. Ceramic balls are approximately 40% lighter, significantly harder, and smoother at the surface level, resulting in lower rolling resistance and reduced heat generation. They are also non-corrosive at the ball contact point. The trade-off is higher cost. For competitive cycling and wet-climate riding, ceramic hybrids offer measurable performance and durability advantages. BOM manufactures both configurations.
Which bearing type is best for bicycle wheel hubs?
Most bicycle wheel hubs use deep groove ball bearings for their combination of radial load capacity, low friction, and effective sealing. High-performance hubs may use angular contact ball bearings for improved axial load handling during cornering. The choice depends on the riding discipline: road hubs prioritize low friction and light weight, while mountain bike hubs need higher load capacity and more robust sealing. BOM manufactures both types with seal and clearance options suited to each application.
What bearings does an E-bike motor require?
E-bike hub motors typically use deep groove ball bearings with enhanced radial clearance to accommodate thermal expansion under motor load. Mid-drive motors use a combination of deep groove and needle roller bearings to support the crankshaft and internal gear stages. Both motor types require effective sealing against road spray and fine debris. BOM manufactures E-bike motor bearings with optimized clearance, multi-layer seals, and heat-resistant lubricants for extended motor service life.
How do I choose the right bottom bracket bearing for my frame?
Bottom bracket bearing selection depends on the frame’s BB shell standard (BSA threaded, BB86 press-fit, BB90, PF30, T47, etc.) and the crankset spindle diameter. Each standard requires specific bearing outer and inner dimensions. BOM manufactures bottom bracket bearings in all major shell standards, with options for stainless steel races, ceramic hybrid balls, and contact seal or labyrinth seal configurations. Custom dimensions are available for proprietary frame designs.
Can BOM manufacture custom bearings for proprietary bicycle component designs?
Yes. BOM manufactures custom bicycle bearings to full specification, including non-standard dimensions, alternative materials (stainless steel, ceramic hybrid), specialized coatings, custom seal profiles, and complete bearing architecture redesign. This supports bicycle OEMs and component brands developing proprietary hub, headset, or bottom bracket systems that do not use standard catalog bearing sizes. Contact BOM’s engineering team with your dimensional and performance requirements.
